Solenoid valve tester

Solenoid valve tester test standard:

The solenoid valve tester mainly tests the pressure, flow and other performance parameters of the solenoid valve. The valve is judged to be qualified if the pressure and flow curves of the valve are within the qualified range

Operation Flowchart of Solenoid Valve Testing Machine

Push the power switch on the circuit breaker.

Press the power key of the all-in-one machine to turn it on.

Rotate the main power switch on the control panel to the "ON" position.

Install the valve seat and wire harness according to the instruction manual.

Open the testing software to start the test.

After the test is completed, close the software and shut down the computer.

Rotate the main power switch on the control panel to the "OFF" position.

Turn off the power switch on the circuit breaker.

VCP Gas Inspection Bench

VCP Gas Inspection Bench Test Standards

The VCP gas inspection bench primarily tests gear unlocking pressure, maximum rotation angle, internal leakage, lock pin clearance, and other performance parameters. Acceptance criteria include performance parameters meeting the tolerances specified in the drawing.

VCP Air-Leak Test Station Operating Flowchart

Turn on the main power switch, power display, and air valve in sequence.

Launch the VCP air-leak test station software and log in.

Select the product model to be tested and load its parameters.

Install and clamp the test fixture that matches the product model.

Start calibration to perform no-load initial torque identification.

Mount the product onto the fixture and secure it firmly.

Press both start buttons simultaneously to begin the performance test.

Record the relevant test data.

OAM solenoid valve leakage test, valve curve test, and valve body test
